Energy Spring NS SYS 305
Marine System Oil
SAE 30 BN 5
NS SYS 305 is a BN 5, SAE 30 system oil for the crankcase and circulation systems of low-speed two-stroke crosshead marine diesel engines. Its detergent and anti-oxidant additive system keeps crankcases, piston undercrowns and oil cooling galleries clean, while a measured alkaline reserve neutralises the combustion acids that leak past the piston rod stuffing box. Highly refined base oils deliver strong oxidation resistance, rapid water separation and the load-carrying capacity required where one charge also serves hydraulics, gearing and stern tubes.
Recommended for the crankcase, bearing and piston-cooling circuits of low-speed two-stroke crosshead marine diesel engines, including electronically controlled designs that draw hydraulic servo oil from the system charge. Also suitable for oil-lubricated stern tubes, turbochargers, reduction gears, deck machinery and other ancillary equipment calling for an SAE 30 oil. Not for use in trunk piston engines, which require a higher BN crankcase oil.
Everllence (MAN ES) NOL
JEC (UE Engines)
MHI-MME
WinGD
Acid Neutralization
A BN 5 alkaline reserve neutralises the cylinder oil and combustion acids passing the stuffing box, protecting bearings and white metal from corrosive attack.
Crankcase Cleanliness
Balanced detergency keeps crankcases, piston undercrowns and oil cooling galleries free of carbon deposits, sustaining heat transfer and oil flow.
Water Separation
Rapid demulsibility and clean centrifuging release water and insolubles from the charge, protecting the system after condensate or cooling water ingress.
Load Carrying Capacity
FZG fail load stage 11, with strong anti-foam and air release, supports use in reduction gears, stern tubes and engine hydraulic servo systems.
Characteristics
| PROPERTY | TEST METHOD | VALUE |
|---|---|---|
| Density at 15°C | ASTM D4052 | 0.891 g/cm³ |
| Kinematic Viscosity @ 40°C | ASTM D445 | 105 cSt |
| Kinematic Viscosity @ 100°C | ASTM D445 | 11.6 cSt |
| Viscosity Index | ASTM D2270 | 98 |
| Pour Point | ASTM D97 | -15 °C |
| Base Number | ASTM D2896 | 5 mgKOH/g |
| Flash Point (COC) | ASTM D92 | 240 °C |
| Load Carrying Capacity, FZG | CEC-L-07-95 | Fail stage 11 |
